Main image Click to view image in fullscreen Refurbished APC WW 20KVA Isolation Transformer APTF20KW01

APC WW 20KVA 208V to 120V Isolation Transformer APTF20KW01 - Refurbished

APC WW 20KVA 208V to 120V RM 4U Isolation Transformer
Model: APTF20KW01
Input: Hardwaire
Output: Hard wire 3-wire (H N + E) 1
Hard wire 3-wire (2P + E) 1
Hard wire 4-wire (2P + N + E) 1
Isolation Transformer
Compatible with Select APC Systems
1 Year Warranty

Extended Warranty

1 Year Included

2 Year + CAD $598.00

3 Year + CAD $1,046.50

Back Order

Quantity

Manufacturer: APC
Model Description: APC WW 20KVA Isolation Transformer, 208V to 120V, RM, 4U
Condition: Refurbished
Part Number: APTF20KW01
Warranty: 1 Year Full Replacement Warranty
Includes: AP7F20KW01 Step down transformer. No accessories included

Please note: This isolation transformer ships on a pallet, freight dock to dock. If you need a liftgate or any special delivery arrangements, please reach out to us prior to orders.

The Step-Down Transformer converts high voltage (208 or 200 VAC) output into low voltage (120 or 100 VAC) output for powering low voltage AC equipment.

APC WW 20KVA Isolation Transformer APTF20KW01 User's Manual

Main:

Main Input Voltage

100V
120V
200V
208V
230V
400V 3 phase

Main Output Voltage

100V
120V
200V
208V
230V

Other Output Voltage

220V
240V
380V
415V

Output Connector Type

Hard Wire 3-wire (H N + E) 1
Hard Wire 3-wire (2PH + G) 1
Hard Wire 4-wire (2PH+N+G) 1

Number of Rack Unit

Physical:

Color	Black
Height	6.89 in (17.5 cm)
Width	17.01 in (43.2 cm)
Depth	29.80 in (75.7 cm)
Net Weight	260.54 lb(US) (118.18 kg)
Mounting Location	Front Side
Mounting Preference	Lower
Mounting Mode	Rack-mounted

Input:

Max Line Current	100A
Input Current Limits	100A
Input Frequency	45...65 Hz
Number of Input Connectors	1 Hard Wire 3-wire (2PH + G) 1 Hard Wire 3-wire (1PH+N+G) 1 Hard Wire 4-wire (2PH+N+G)

Output:

Maximum Total Current Draw per Phase	100A
Efficiency	96%

Conformance:

Product Certifications	CSA UL Listed
Standards	EN 55022 Class A EN 55024 EN 60950 EN 61000-3-2 EN 61000-3-3

Environmental:

Ambient Air Temperature for Operation	32…104 °F (0…40 °C)
Relative Humidity	0…95 %0…95%
Operating Altitude	0...10000 ft
Ambient Air Temperature for Storage	32…104 °F (0…40 °C)
Storage Relative Humidity	0…95%
Storage Altitude	0…10000 ft (0.00…3048.00 m)
