Main image Click to view image in fullscreen Tripp Lite PDUMH30HV19NET 5500W Single-Phase Switched PDU Out:(8)C13 & (6)C19 - Refurb

Tripp Lite PDUMH30HV19NET 5500W Single-Phase Switched PDU Out:(8)C13 & (6)C19 - Refurb

Tripp Lite 5500W Single-Phase Switched PDU, 200-230V, RM 2U 30A
Model: PDUMH30HV19NET
Input: (1) NEMA L6-30P (200-230V - 30A)
Output: (8) C13, (6) C19
Refurbished PDU
1 Year Warranty Included

Additional Warranty

1 Year Included

2 Year + CAD $138.00

3 Year + CAD $241.50

Back Order

Quantity

Manufacturer: Tripp Lite
Model: PDUMH30HV19NET
Description: Tripp Lite 5500W Single-Phase Switched PDU 230V Output:(8) C13, (6) C19
Input: (1)L6-30P (200-230V - 30A)
Output: (8) C13, (6) C19
Condition: Refurbished
Warranty: 1 Year Full Replacement Warranty, additional warranty available

Tripp Lite 5500W Single-Phase Switched PDU 230V - User Manual

Tripp Lite PDUMH30HV19NET Specifications:

Overview

PDU Type

Switched

Input

Input Phase

Single-Phase

PDU Input Voltage

208; 230

Recommended Electrical Service

Single-phase 30A 208/230V service

Maximum Input Amps

Maximum Input Amps Details

Agency rated to 24A continuous

PDU Plug Type

(1) NEMA L6-30P

Input Cord Details

Set of two inputs connect to separate PRIMARY and SECONDARY power sources

Input Cord Length (m)

3.66

Output

Output Capacity Details

5.5kW (230V), 5kW (208V) total capacity / 30A max (Agency de-rated to 24A), 20A max per breakered outlet bank; 16A max per C19 outlet; 12A max per C13 outlet

Frequency Compatibility

50 / 60 Hz

Output Receptacles

(8) C13; (6) C19

Output Nominal Voltage

208/230V

Overload Protection

Three 20A circuit breakers; Breaker 1 (Bank 1 C13 outlets #1-8), Breaker 2 (Bank 2 C19 outlets #9-11), Breaker 3 (Bank 2 C19 outlets #12-14)

Customized Load Management
Receptacles

Each outlet is individually controllable via remote interface

User Interface, Alerts & Controls

Front Panel LCD Display

2 digit meter and pushbutton display toggle switch reports output current in amps in 3 loading segments, Bank 1 (C13 outlets #1-8), Bank 2 (C19 outlets #9-14) and Banks 1&2 combined (Outlets #1-14)

Front Panel LEDs

14 power availability LEDs confirm power off/on status for each built-in outlet; Two additional LEDs identify which bank the visual current meter is reporting (Bank 1, Bank 2 or Banks 1&2 combined)

Switches

Pushbutton near the two digit current meter toggles reporting of output amps on Bank 1, Bank 2 and Total PDU output (Banks 1 & 2 combined)

Physical

Material of Construction	Metal
Form Factors Supported	2U rackmount
Minimum Required Rack Depth (cm)	40.64
PDU Form Factor	Horizontal (2U)
Unit Dimensions (hwd / cm)	8.9 x 44.5 x 31.75
Unit Weight (kg)	6.26

Environmental

Operating Temperature Range

32° to 104°F (0° to 40°C)

Storage Temperature Range

-22° to 122°F (-30° to 50°C)

Relative Humidity

5% to 95% non-condensing

Operating Elevation (m)

0-10000 ft. (0-3000 m)

Communications

PowerAlert Software	LX Platform Interface: PowerAlert Device Manager
Communications Cable	Micro-USB- to-USB A configuration/console Access cable
Network Monitoring Port	RJ45 Network port, Micro-USB Configuration port, USB A port supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules.
SNMP Compatibility	LX platform interface provides remote monitoring via Java-free HTML5 web interface, telnet, SSH and SNMP management systems.
Network Compatibility	10 Mbps; 100 Mbps (Fast Ethernet)
Communications Interface	Network card WEBCARDLX ; USB

Features & Specifications

High Availability PDU Features

Auto Probe Monitoring and Reboot (included); Auto-Transfer Switching; Auto Load Shedding

Standards & Compliance

Product Certifications	NOM (Mexico); UL 60950-1
Product Compliance	RoHS; FCC Part 15 Class A (USA); Trade Agreements Act (TAA)
